| Belt | Colour | Material | No. of PLY | Thickness (mm) | Weight (kg/sq. m) | SD Value | Min. Pulley Dia. | Permissiible Temp. |
|---|---|---|---|---|---|---|---|---|
| PBS 5/1 0/2U MT | White. | PU | 1 | 0.8 | 1.0 | 4 | 6 | -20 to +90°C |
| PBS 5/1 0/2V MT | White, Green. | PVC | 1 | 1.0 | 0.85 | 5 | 6 | -20 to +90°C |
| PBS 6/2 0/2U MT | White. | PU | 2 | 1.5 | 1.65 | 6 | 6 | -20 to +90°C |
| PBS 8/2 0/v/0 | Transp. | PVC | 2 | 1.3 | 1.3 | 8 | 15 | -10 to +90°C |
| PBS 8/2 0/5V MT | White, Green, Black. | PVC | 2 | 2.0 | 2.2 | 8 | 25 | -15 to +90°C |
| PBS 8/2 0/4V CP | Black. | PVC | 2 | 2.0 | 2.1 | 8 | 25 | -15 to +80°C |
| PBS 8/2 0/15V LGP | Black. | PVC | 2 | 3.1 | 3.4 | 8 | 60 | -10 to +70°C |
| PBS 8/2 7V/8V DP | White, Green. | PVC | 2 | 3.0 | 3.4 | 8 | 70 | -10 to +70°C |
| PBS 8/2 0/30V ASP | Green. | PVC | 2 | 4.5 | 3.9 | 8 | 40 | -15 to +80°C |
| PBS 8/2 0/7V BW | Green. | PVC | 2 | 2.4 | 2.6 | 8 | 60 | -10 to +70°C |
| PBS 28/1 1V/1V PVK | Black. | PVK | 1 | 4.5 | 5 | 28 | 120 | -12 to +90°C |
| PBS 10/2 0/12V MT | White, Green, Black. | PVC | 2 | 3.0 | 3.9 | 10 | 50 | -15 to +80°C |
| PBS 12/2 0/25V MT | Black. | PVC | 2 | 4.0 | 3.9 | 12 | 80 | -10 to +70°C |
| PBS 12/2 0/5E MT | White. | Polyolefin | 2 | 2.6 | 2.6 | 12 | 60 | -10 to +70°C |
| PBS 18/3 0/10U MT | Black. | PU | 3 | 3.5 | 4.0 | 15 | 120 | -20 to +90°C |
| PBS 18/3 0/15U CP | Green. | PU | 3 | 3.5 | 3.5 | 15 | 120 | -20 to +90°C |
| PBS 70/4 0/70 RWT | Green. | PVC | 4 | 12.5 | 13 | 70 | 400 | -15 to +80°C |
| PBS 40/4 0/25V RP | Green. | PVC | 4 | 9.0 | 10.3 | 40 | 500 | -15 to +80°C |
| PBS 80/10U/20U TEWB | Green. | PU | 1 | 4-10 | - | 80 | 80 | -20 to +90°C |
| PBS NOVO250 | Black. | ELASTOMER | WOVEN | 2.5 | 1.3 | 8 | 40 | -10 to +120°C |
| PBS NOVO400 | Black. | ELASTOMER | WOVEN | 4.0 | 2.2 | 8 | 70 | -10 to +120°C |
| PBS NOVO600 | Black. | ELASTOMER | WOVEN | 5.5 | 3.1 | 8 | 120 | -10 to +120°C |
| Desigantion | Sizes b*h*(s)[mm] | Weight Approx. [g/m] | Use as Lateral Profile | Use as Longitudinal Profile | |||
|---|---|---|---|---|---|---|---|
| a2 min[mm] | d min approx.[mm] | a1 min[mm] | d min approx.[mm] undersize | d min approx[mm] top face | |||
| K 6 | 6*4*4 | 25 | 30 | 30 | 30 | 40 | 30 |
| K 10 | 10*6*6 | 60 | 30 | 50 | 30 | 70 | 60 |
| K 13 | 13*8*7.5 | 100 | 30 | 80 | 30 | 100 | 70 |
| K 15 | 15*8*9.5 | 120 | 30 | 90 | 30 | 100 | 80 |
| K 17 | 17*11*9.5 | 180 | 30 | 110 | 30 | 110 | 90 |
| K 30 | 30*16*18 | 470 | 60 | 180 | 50 | 230 | 190 |
| K 20 | 20*20 | 160 | 30 | 90 | 40 | 120 | |
| K 60 | 70*60 | 1450 | 100 | 150 | |||
| K 60 | 33*60 | 600 | 90 | 80 | |||
| K 80 | 46*80 | 1200 | 100 | 140 | |||
| K 20*3 | 20*3 | 75 | 30 | 70 | 30 | 70 | 50 |
| K 30*8 | 30*8 | 290 | 40 | 120 | 45 | 120 | 90 |
